Axpert Ultra Series
Price range: ₨ 250,000 through ₨ 289,773
Axpert Ultra Series High-Power Hybrid Solar Inverter
Power your home or business with our advanced Axpert Ultra hybrid solar inverters, available in 8kW and 11kW models. Designed for high-demand applications, these inverters feature dual MPPT technology, parallel capability up to 6 units, and massive 150A charging current for rapid battery replenishment. With selectable input voltage ranges for both personal computers (170-280V) and home appliances (90-280V), pure sine wave output, and 10ms transfer time, they ensure seamless backup power during grid failures. Built with robust 48V battery system compatibility and comprehensive communication interfaces including USB, RS232, RS485, WiFi, and dry contact.
Price range: ₨ 250,000 through ₨ 289,773
Axpert Ultra Series High-Power Hybrid Solar Inverter – Complete Specifications
8kW and 11kW models with dual MPPT, parallel capability, and rapid charging for residential and commercial applications
Key Features & Important Notes:
- High Power Capacity: 8kW and 11kW models for demanding residential and commercial applications
- Parallel Operation: Support for up to 6 units in parallel for scalable power expansion
- Dual MPPT Technology: Two independent MPPT controllers with up to 13000W PV array capacity
- Massive Charging Current: 150A maximum charging current for rapid battery charging
- Wide Input Voltage Range: Selectable 170-280V (PC mode) or 90-280V (Appliance mode) for grid flexibility
- Fast Transfer Time: 10ms transfer for sensitive electronics, 20ms for appliances
- Pure Sine Wave Output: Clean power compatible with all sensitive electronic equipment
- High Surge Capability: 16000VA (8kW) and 22000VA (11kW) surge power for motor starts
- Comprehensive Communication: USB, RS232, RS485, WiFi, dry contact, and BTS interfaces
- Advanced Protection: Optional GFCI, Rapid shutdown, and AFCI detection support
- Built-in Current Sensor: External current transformer sensor port for energy monitoring
- 48V Battery System: Standard 48VDC battery voltage with 54V floating charge
| Parameter / Model | Axpert Ultra 8K | Axpert Ultra 11K |
|---|---|---|
| General Specifications | ||
| Rated Power | 8000 VA / 8000 W | 11000 VA / 11000 W |
| Parallel Capability | YES, up to 6 units | |
| Input Specifications | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) |
|
| Frequency Range | 50 Hz / 60 Hz (Auto sensing) | |
| Output Specifications | ||
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% | |
| Surge Power | 16000 VA | 22000 VA |
| Efficiency (Peak) | 93% | |
| Transfer Time | 10 ms (For Personal Computers) 20 ms (For Home Appliances) |
|
| Waveform | Pure sine wave | |
| Battery Specifications | ||
| Battery Voltage | 48 VDC | |
| Floating Charge Voltage | 54 VDC | |
| Overcharge Protection | 63 VDC | |
| Solar Charger & AC Charger | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 12000 W (6000W × 2) | 13000 W (6500W × 2) |
| MPPT Range @ Operating Voltage | 90 ~ 450 VDC | |
| Maximum PV Array Open Circuit Voltage | 500 VDC | |
| Maximum PV Input Current | 27A × 2 (MAX 40A) | |
| Maximum Solar Charge Current | 150 A | |
| Maximum AC Charge Current | 120 A | 150 A |
| Maximum Charge Current | 150 A | |
| Physical Specifications | ||
| Dimension, D × W × H (mm) | 145 × 438 × 553.6 mm | |
| Net Weight (kgs) | 18.4 kg | |
| Communication Interface | USB / RS232 / RS485 / WiFi / Dry-contact / BTS Support optional GFCI, Rapid shutdown, AFCI detection |
|
| External Current Sensor Port | Yes, built-in current transformer sensor | |
| Operating Environment | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10°C to 50°C | |
| Storage Temperature | -15°C to 60°C | |
| Standards | ||
| Compliance Safety | CE | |
Product specifications are subject to change without further notice.
